CA624 CLUTCH ASSEMBLY CVC 7pk for RENAULT MEGANE II /SCENIC II 8200600110 / 8200678499 / 8671016163 / 92600BN701 /8200470242

Specifications

Model number: CA624

CLUTCH DIA: 119 mm

Bearing size: 35 x 55 x 20 mm

Number of streams (belt teeth): 7PK

Voltage: 12V

Seat height: 15.5mm

Shaft spline diameter: 12.6mm

Number of slots: 23

Inner diameter of the coil seat: 66 mm

Pressure plate diameter: 110 mm

Coil diameter: 101 mm

Coil Width: 26 mm

Type: CVC

Coil# CC508

Hub# EK328

Application:

RENAULT MEGANE II (1.4, 2.0, 1.9dCi) / SCENIC II (1.9dCi, 2.0)

OEM no.

8200678499

8200940235

7711135808

8200053264

8200309193

01140018

8200940233

8200457418

8671016164

8200678499 / 32066862 / TSP0155972 / 8200678504 / 8200940235 / 7711135808 / 8200053264 / 8200309193 / 01140018 / 8200678499 / 8200940233 / 8200457418 / 8200309193 / 7711135808 / 8200053264 / 8200678499 / 32066862 / 32066862 / 8200457418 / 8200678499 / 8200940233 / 7711135105 / 8200050141 / 8200316164 / 8200470242 / 8200600110 / 8200678499 / 8671016163 / 92600BN701
