CA101 CLUTCH ASSEMBLY CSV613/CSV717 4pk for BMW X5 (E70) X6 (E71) 64509182796 64529145353 64529185143 6905643/6918752

Specifications

Model number: CA101

Coupling diameter (by belt): 110 mm

Coupling diameter (total): 110 mm

Bearing size: 35 x 55 x 20 mm

Number of streams (belt teeth): 4PK

Voltage: 12V

Seat height: 15.5mm

Shaft spline diameter: 12.5mm

Number of slots: 23

Inner diameter of the coil seat: 64 mm

Pressure plate diameter: 110 mm

Coil diameter: 96 mm

Coil Width: 32 mm

Type: CSV613/CSV717

Application:

BMW X5 (E70), X6 (E71) with N52 engine

BMW X5-X6 (E70-E71) with N52 3.0 petrol engine, 2007-2013 model years.

OEM no.

64509182796

64529145353

64529185143

6905643 / 6918752 / 64526905643 / 64526918752 / 64529145353 / 9145353 / 64526945550 / 64529158038 / 6945550 / 9158038

70763

97958

510246

64526905642

64526905643

64526918752

64526933307

64526945550

64526950789

64529145353

64529158038

3R41045010

3R410-45010

3R41145010

3R411-45010

3R41245010

3R412-45010

3R41445010

3R414-45010

3R41545010

3R415-45010

51-0246

A4101130A020

A4101130A021

A4101130A022

A4101130A023

A4101130A024
